VIDEO CHAPTERS
0:00 – Intro
6:23 – Kit Description and procedures
10:00 – How to safely remove adhesive pads
12:00 – Removing Wii front face
15:00 – Optical drive removal
17:00 – Which screw goes where
24:50 – AVE-HDMI kit prep
27:00 – Prepping the soldering site
29:15 – Removing conformal coating/solder resist
35:30 – Precisely aligning the AVE-HDMI kit over vias
38:25 – Soldering the remaining loose wire connections
41:29 – Explaining how to wire the 3v3 and mode select
42:38 – Installing the HDMI interposer over the USB header
48:25 – Case filing & prep for HDMI port cutout
55:00 – Test system before reassembly
56:15 – Reassemble the system
58:07 – How to carefully reconnect the optical drive
1:03:46 – Outro
1:07:04 – RetroTink 4k Captures
#Wii #hacker
